The Ultra-Fast Quad-Laser System with a Large Building Volume
Designed for industrial applications, the EOS M400-4 offers a large building volume of 400 x 400 x 400mm combined with four lasers for up to four times higher productivity.
It shatters boundaries of manufacturing as it meets the most demanding requirements of modern production environments in terms of efficiency, scalability, usability and process monitoring. The modular platform design can easily be integrated into existing production environments and flexible consolidated with future innovation.
Building volume plus speed
- Large building volume of 400 x 400 x 400mm with four 400 watt lasers operating independently
- The four precise 400 watt fibre lasers operate in a 250mm x 250mm square each with an overlap area of 50mm
- High build rate of 100cm³/h
High productivity platform with smart process flow
- Wide range of materials: from light metals to stainless and tool steels to superalloys
- Easy handling through a high degree of automation in workflow and operation
- Intuitive user interface, flexible software tools and a variety of additional equipment fulfill industrial production requirements
4 Lasers – First-class DMLS quality
- Exceptional beam and power stability provides highest DMLS part quality
- All processes running on the EOS M290 can be transferred to the EOS M400-4 and deliver equivalent part properties
- New and patented EOS ClearFlow Technology ensures consistent process gas management for ideal build conditions
- Extensive monitoring features ensure high process stability and part quality
Technical Data
EOS M 400-4 Building volume 400 mm x 400 mm x 400 mm (15.8 x 15.8 x 15.8 in) (including building plate) Laser type Yb-fibre laser; 4 x 400 W Precision optics 4 F-theta-lenses; 4 high-speed scanners Scan speed up to 7.0 m/s (23 ft/s) Focus diameter approx. 100 µm (0.004 in) Power supply 3 x 50 A Power consumption max. 45 kW / typical 22 kW Inert gas supply 7,000 hPa; 20 m³/h (102 psi; 706 ft³/h) Dimensions (W x D x H) System 4,181 mm x 1,613 mm x 2,355 mm (164.6 x 63.5 x 92.7 in) Recommended installation space min. 6.5 m x 6 m x 3.3 m (256 x 236 x 130 in) Weight approx. 4,835 kg (10,659 lb) Software EOS RP Tools; EOSPRINT; EOS ParameterEditor; EOSTATE Everywhere; EOSTATE PowderBed; Materialise Magics RP and modules EOS RP Tools; EOSPRINT; EOS ParameterEditor; EOSTATE Everywhere; EOSTATE PowderBed; Materialise Magics RP and modules Optional accessories Optional accessoires EOSTATE Laser, IPM M Powder Station L*, IPM M UnpackStation L* EOSTATE Laser, IPM M Powder Station L*, IPM M UnpackStation L* * Currently under development
