A TOTAL SYSTEM FOR STEREOLITHOGRAPHY
Shortening product development spans, producing smaller lots, reducing production costs…
Improving production efficiency, has become an important theme for all kings of modern businesses. Stereolithography is capable of 3-dimensional modeling with higher speed and greater precision, is essential technology for improving business competitiveness.
The Solid Creation System (SCS) is a total modeling system, with hardware from Global SONY, UV-curable resin from the synthetic resin authority JSR, and technical support provided by D-MEC.
A TOTAL SYSTEM FOR STEREOLITHOGRAPHY
Shortening product development spans, producing smaller lots, reducing production costs…
Improving production efficiency, has become an important theme for all kings of modern businesses. Stereolithography is capable of 3-dimensional modeling with higher speed and greater precision, is essential technology for improving business competitiveness.
The Solid Creation System (SCS) is a total modeling system, with hardware from Global SONY, UV-curable resin from the synthetic resin authority JSR, and technical support provided by D-MEC.
Advantages for design & development
- texture & shape can be verified by actually viewing the model
- grip feeling and other human engineering aspects can be experienced with actual object.
- design verification can be done easily at the concept stage or when specifications are changed
- functional evaluations & tests can be shortened & streamlined.
Advantages for production technology
- assembly workability, and in particular any interference in the work track, can be checked in advance
- jig used in assembly can be reviewed in advance
- workability after deformation under load can be checked
- the prototype process for molds becomes unnecessary, allowing the production phase to be reached quickly
Advantages for sales
- Customers can be provided with models as prototype samples
- Communication with customers can be made smoother and negotiations more advantageous
- Consideration of product price can be made easier
Advantages for management
- Molds for production can be made without going through the prototype process, reducing the time and costs required for development
- Proposals for multiple shapes can be compared and reviewed in a short time, speeding the decision-making process
- Smooth interaction between departments is facilitated
- prototypes which used to be assigned to professionals can now be easily created by anyone, contributing to business streamlining.
Technical Data
Laser Solid-state semiconductor laser - 1000mW, 60kHz Modulator Built-in Deflection Equipment Galvanometer mirror system (includes sweep-defocus correction function) Model Creation Range 610 x 610 x 500mm Spot Size 0.15 - 0.4 mm (automatic adjustment) Scan Speed Max. 10m/s Layer Thickness 0.1 - 0.2mm Tank Volume 280L (replaceable; wheeled) Power Source 100VAC40A Coolant Not needed Main Unit Dimensions (W x D x H) (mm) 1940 x 1150 x 1660 (excluding signal tower & projections) Main Unit Weight (including resin) 1700 kg
