The Benchmark for the industrial 3D printing of High-Quality Metal Parts - with Enhanced Quality Management Features
With a building volume of 250 x 250 x 325mm, the EOS M290 allows a fast, flexible and cost-effective production of metal parts directly from CAD data.
An intuitive user interface, the intelligent software concept with a combination of open and standardized parameter sets and the improved filter system are specially designed for the industrial production.
Modular Components
- 400-watt fibre laser provides an exceptionally high beam quality combined with performance stability
- System operates in protective nitrogen as well as argon atmospheres. This allows the system to process a wide range of materials
Extensive Portfolio
- Wide range of materials: from light metals to stainless and tool steel to superalloys
- Broad range of applications: EOS ParameterSets manufacture parts with standardized Part Property Profiles (PPPs)
- The ParameterEditor enables you to modify parameters to meet individual requirements
Enhanced monitoring
- Three new modules EOS PowderBed, EOSTATE Base, EOSTATE LaserMonitoring enable quality management at the highest level
- Optimized for the requirements of industrial production
Proven quality
- Tool-free manufacturing of high-quality metal serial components, spare parts and functional prototypes
- Enhancement of the well-known EOSINT M280, the leading system on the market
Optimized process gas management
- Fewer filter changes and longer lifetime thanks to a recirculating filter system with automated self-cleaning
Intuitive software
- System can be operated via touch screen
- Graphical user interface for an intuitive, task-based machine operation
- Wizard guidance supports the system operator
Technical Data
EOS M 290 Building volume 250 mm x 250 mm x 325 mm (9.85 x 9.85 x 12.8 in) Laser type Yb-fibre laser; 400 W Precision optics F-theta-lens; high-speed scanner Scan speed up to 7.0 m/s (23 ft./sec) Focus diameter 100 μm (0.004 in) Power supply 32 A Power consumption max. 8.5 kW / typical 3.2 kW Nitrogen generator integrated Compressed air supply 7,000 hPa; 20 m³/h (102 psi; 706 ft³/h) Dimensions (B x D x H) System 2,500 mm x 1,300 mm x 2,190 mm (98.4 x 51.2 x 86.2 in) Recommended installation space min. 4,800 mm x 3,600 mm x 2,900 mm (189 x 142 x 114 in) Weight approx. 1,250 kg (2,756 lb) Data preparation Software EOS RP Tools; EOSTATE; EOSPRINT; Materialise Magics RP with SG+ and further modules CAD interface STL. Optional: converter for all standard formats Network Ethernet EOS monitoring solutions available
EOS Monitoring-Products EOS M 400 EOS M 290 EOSINT M 280 / M 270 1 EOSTATE Base ✕ ✕ ✕ EOSTATE Laser ✕ ✕ ✕ 2 EOSTATE Modul QualityAssurance ✕ ✕ ✕ EOSTATE Modul Controlling ✕ ✕ ✕ EOSTATE Modul MachinePark ✕ ✕ ✕ 3 EOSTATE PowderBed ✕ ✕ 4 EOSTATE MeltPool ✕
