Ideal entry level model for industrial 3D printing
High-End System for the Fast and Efficient Production of Complex Metal Parts by Means of Additive Manufacturing
The size and modular design of the EOS M100 make it ideal as an entry level model for Additive Manufacturing. In terms of process and component quality, it corresponds to the EOS M290, the leading system on the market for Direct Metal Laser Sintering (DMLS).
Ideal entry level model for industrial 3D printing
High-End System for the Fast and Efficient Production of Complex Metal Parts by Means of Additive Manufacturing
The size and modular design of the EOS M100 make it ideal as an entry level model for Additive Manufacturing. In terms of process and component quality, it corresponds to the EOS M290, the leading system on the market for Direct Metal Laser Sintering (DMLS).
Outstanding Quality & Detail Resolution
- The beam quality and stable performance of the 200 watt fibre laser guarantee optimum, constant processing conditions for the production of high-quality components.
- The smaller laser spot with excellent detail resolution is ideal for manufacturing highly complex, sophisticated DMLS components.
Cost-efficient production
- The building volume and efficient recoating and exposure strategy reduce secondary time, so that parts can be produced quickly and efficiently in small quantities.
Quick & Easy Handling
- Thanks to the modular inner design and the powder supply bin, setup and shutdown only take minutes, changing material is straightforward and maintenance is done quickly.
Extensive Portfolio
- The peripheral devices are matched to the industrial manufacturing process and ensure minimum powder contact.
Technical Data
EOS M 100 Building volume Ø 100 mm x 95 mm (Ø 3.9 in x 3.7 in) height, incl. build platform Laser type Yb-fibre laser; 200 W Precision optics F-theta-lens; high-speed scanner Scan speed up to 7.0 m/s (23 ft./sec) Focus diameter 40 μm Power supply 200 - 240 V Power consumption max. 1.7 kW Inert gas supply max. 4,000 hPa, 50 l/min Dimensions (B x D x H) System 800 mm x 950 mm x 2,250 mm (31 x 37 x 89 in) Recommended installation space min. 1,00 m x 3,00 m x 2,5 m (3 x 10 x 8 ft) Weight 580 kg Software EOSPRINT, EOS RP Tools, CAMbridge or Magics RP and other modules Materials* EOS CobaltChrome SP2 (CE-certified, CE 0537), EOS StainlessSteel 316L, EOS Titanium Ti64** Optional accessories EOSTATE Laser, powder conveying and sieving module**, wet separator, blasting cabinet * Further materials on request ** Currently under development
